Built for Versatility: Multi-Format PET Extrusion

Large Image : Built for Versatility: Multi-Format PET Extrusion

Product Details:

Place of Origin:	CHINA
Brand Name:	CHUQI

Payment & Shipping Terms:

Minimum Order Quantity:	1SET
Packaging Details:	WOODEN BOX
Delivery Time:	60DAYS
Payment Terms:	T/T
Supply Ability:	100SETS

Contact Now

Built for Versatility: Multi-Format PET Extrusion

Description

Product Breadth:	Wide-Range Multi-Specification	Core Capability:	Quick Changeover
Width Range:	5-30mm	Thickness Range:	0.3-2.0mm
Process Flexibility:	Adjustable Draw Ratios & More	Market Value:	Agile Response To Small-Batch, Multi-Variety Demand
Highlight:	PET extrusion production line , multi-format PET strap machine , versatile PET strap extruder

Built for Versatility: Multi-Format PET Extrusion

Product Introduction

Our multi-format PET extrusion production line is engineered as a versatile platform capable of adapting to rapidly changing market demands. This flexible system enables efficient switching between various PET product specifications—including widths from 5mm to 30mm, thicknesses from 0.3mm to 2.0mm, and cross-sectional shapes such as flat strap, monofilament, and rectangular bar—through quick-change modular components and adjustable process parameters. This versatility supports agile, small-batch, multi-variety production while minimizing equipment investment.

Main Specifications

Modular Die System: Quick-change connection system with multiple die configurations (1-out-2, 1-out-4, 1-out-6, various lip shapes) enabling product changeover within hours
Adjustable Haul-off & Stretch Units: Variable haul-off roller width and nip with infinitely adjustable draw ratios to meet specific mechanical property requirements
Configurable Cooling & Setting Paths: Adjustable cooling roll layouts and water tank guide paths tailored to different product cooling needs
Flexible Winding Solutions: Options include single-spindle, dual-spindle, or multi-position winders for various roll weights and packaging requirements
Universal Control System: Wide parameter setting range with multiple recipe storage capacities for efficient management of diverse product processes

Technical Parameters

Parameter Category	Parameter Item	Specification / Description
Product Range	Producible Width	5 - 30 mm (via die change)
	Producible Thickness	0.3 - 2.0 mm
	Product Forms	Strapping, Sheet, Monofilament, Profile
Changeover Capability	Die Quick-Change Time	≤ 4 hours (standard operation)
Changeover Capability	Process Recipe Storage	≥ 50 recipes
Equipment Adaptability	Haul-off Roll Effective Width	Typically > 2x the max product width
Equipment Adaptability	Draw Ratio Adjustment Range	MD: 1.5-8.0x, TD: 1.0-5.0x
Production Mode	Supported Modes	High-volume single product / Low-volume multi-product

Frequently Asked Questions

Q1: What adjustments are needed when switching from narrow strap to wide sheet besides the die? Is it complex?

Main adjustments include: 1) Changing the die and flat die lip for the corresponding width. 2) Adjusting cooling roll spacing and contact angle for uniform cooling of the wide sheet. 3) Resetting tension parameters for haul-off and winding, as total tension is higher for wide sheets. 4) Possibly adjusting the stretching process. This procedure is covered in our training and SOPs, and our control system supports saving a separate "wide sheet" recipe, making the switchover process streamlined and repeatable, not complex.

Q2: With one line doing so many specifications, will it be a jack of all trades, master of none?

No. "Versatile" does not mean "compromised." The line's core precision platform (temperature control, speed control, tension control) maintains high standards. When switched to a specific product, we use dedicated dies and process recipes optimized for that product to achieve its best performance. Like a high-performance camera with different lenses for various subjects, our line platform ensures excellent foundational performance, while dedicated dies and recipes ensure each product specification is mastered.
