Real-Time Production Data Display: Speed, Length, Tension & Temperature

Real-Time Production Data Display: Speed, Length, Tension & Temperature
Real-Time Production Data Display: Speed, Length, Tension & Temperature

Large Image :  Real-Time Production Data Display: Speed, Length, Tension & Temperature

Product Details: Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: wooden box
Delivery Time: 60days
Supply Ability: 100sets
Contact Now

Real-Time Production Data Display: Speed, Length, Tension & Temperature

Description
Data Dimension: Temperature Data Characteristic: Real‑time Display
Presentation Mode: Graphical Interface Management Function: Status Monitoring & Traceability
Highlight:

PP strapping band production line monitor

,

real-time strapping production data display

,

PP band line speed tension monitor

Real-Time Production Data Display: Speed, Length, Tension & Temperature
Product Introduction

Production process transparency and digitization form the foundation of refined management and quality traceability. Our production line PLC control system features comprehensive real-time data monitoring and display capabilities. Operators can monitor all critical line parameters at a glance on the central touch screen, including:

  • Real-time extruder and heating zone temperatures
  • Instant line speeds for main drive and traction units
  • Meterage counts for every winding shaft
  • Tension feedback values at critical stations

All data updates dynamically through numeric displays, gauge dials, and trend curves, providing complete production status visibility. This delivers immediate, accurate data support for process optimization, efficiency analysis, and rapid fault troubleshooting.

Main Specifications
  • Display Content: Four core parameters—Speed, Length (Meterage), Tension, and Temperature
  • Data Characteristics: Real-time, centralized, and visual presentation
  • Display Interface: High-definition color touch screen with multi-screen switching capability
  • Management Value: Enables production status visualization and supports data-driven decision-making and problem traceability
Technical Parameters
Item Parameter / Description
Data Display Types Numeric values, bar graphs, analog gauges, real-time trend curves
Key Monitoring Parameters Extruder Zones 1-7 temperature; Oven Zones 1-4 temperature; Main drive, traction, and winding line speeds; Meterage counts 1-4; Tension feedback from stretcher/traction units
Refresh Rate ≤ 1 second, ensuring real-time data performance
History Traceability Key parameters (e.g., temperature) can retrieve short-term historical curves (e.g., last 1 hour)
Alarm Integration Data anomalies (e.g., over-temperature, over-speed) trigger alarms with highlighted prompts in corresponding data fields
Operational Convenience Important parameters can be set on the main monitoring page for easy overview
Frequently Asked Questions
What can these real-time data be used for?
Wide range of applications:
  • Process monitoring – Ensuring stable operation within set parameters
  • Problem diagnosis – Quickly locating abnormal sections by reviewing temperature and speed curves when product quality fluctuates
  • Efficiency statistics – Calculating shift or daily output through meterage data
  • Preventive maintenance – Monitoring indirect parameters such as motor current to predict potential failures
How long can the data be stored? Can it be exported for analysis reports?
The standard PLC internal memory primarily handles short-term buffering and real-time display, and generally does not perform long-term mass data storage. If long-term recording and data export for report generation are required, an external data logger or upper-computer software is usually needed as an optional extension. We can provide corresponding solutions based on your management needs.
Can operators quickly identify issues from so much data?
Yes, because the system is designed with alarm prioritization and anomaly highlighting. For example:
  • When a zone temperature exceeds the limit, the temperature value turns red and flashes
  • When the meterage reaches a preset value, a roll-change prompt pops up
Operators mainly need to check for alarm prompts and whether key parameters remain within the set green normal range, without having to interpret all specific values constantly.
