Adjustable Cooling Water Temperature from 10°C to 25°C

Adjustable Cooling Water Temperature from 10°C to 25°C
Adjustable Cooling Water Temperature from 10°C to 25°C

Large Image :  Adjustable Cooling Water Temperature from 10°C to 25°C

Product Details:
Place of Origin: CHINA
Brand Name: CHUQI
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: wooden box
Delivery Time: 60days
Payment Terms: T/T
Supply Ability: 100sets
Contact Now

Adjustable Cooling Water Temperature from 10°C to 25°C

Description
Control Parameter: Water Temperature Adjustment Range: 10-25°C
Control Accuracy: High (±1°C) System Configuration: Requires External Temperature Control Unit
Process Impact: Controls Crystallization Quality Relevance: Performance & Appearance
Application Flexibility: High
Highlight:

adjustable cooling water temperature system

,

PP strapping band cooling system

,

water temperature control 10°C to 25°C

Adjustable Cooling Water Temperature from 10°C to 25°C
Product Introduction
The cooling process is a critical component in controlling the crystallization rate of PP products, directly determining their final properties and appearance. This production line features an advanced cooling water temperature control system that enables precise adjustment within the range of 10°C to 25°C. Through integration with refrigeration or cooling tower systems, the water temperature can be maintained consistently at the desired set point. This precise temperature control capability allows optimization of cooling conditions for various raw material properties and product requirements—such as high strength, high toughness, and high clarity—ensuring stable control over product crystallinity, internal stress, dimensional stability, and surface gloss.
Main Specifications
  • Control Range: Working temperature of cooling water adjustable between 10°C - 25°C
  • Control Method: Achieved via external refrigeration system or cooling tower; the machine provides temperature monitoring and control interface
  • System Composition: Stainless steel cooling tanks, temperature sensors, circulating water pumps, and external temperature control unit
  • Process Value: Optimizes product crystallization process and stabilizes product quality through precise temperature control
Technical Parameters
Item Parameter
Water Temp. Adjustment Range 10 - 25 °C
Water Temp. Control Accuracy ±1 °C (dependent on external temp. control system performance)
Total Cooling Length Primary Cooling Tank 3.0m + Secondary Setting Tank 5.5m
Tank Material 304 Stainless Steel
Circulating Water Flow Rate ~5 Tons/hour
Control Interface Provides water temperature display and interface for linkage signals to external temperature control systems
Customer Questions & Answers
Q: How does water temperature specifically affect the product? How to choose the appropriate temperature?
A: Low-temperature cooling (e.g., 10-15 °C): Fast cooling, high crystallization rate, relatively lower product crystallinity, potentially higher internal stress, beneficial for achieving high rigidity and hardness, but may be slightly brittle. Higher temperature cooling (e.g., 20-25 °C): Slower, gentler cooling favors orderly molecular chain arrangement, can increase crystallinity, reduce internal stress, often resulting in better product toughness, dimensional stability, and surface gloss. Selection requires testing and optimization based on raw material and product performance goals.
Q: What additional equipment do we need to purchase to achieve this temperature control?
A: You will need to configure corresponding industrial chillers (for precise refrigeration) or cooling towers (utilizing evaporative cooling) based on production capacity and local climate. The production line itself provides temperature monitoring and the circulating water circuit, but the active cooling function is performed by these external units. We will provide the necessary heat load data for your selection.
Q: Does the cooling water require special treatment? Can we use tap water directly?
A: Long-term direct use of untreated tap water is not recommended, as scale and microorganisms can clog pipelines, contaminate products, and reduce heat exchange efficiency. The use of softened water or regular addition of water treatment chemicals is advised, and maintaining a closed cycle system helps minimize impurities and evaporation loss.

Tag:

synchronous PP strapping line,

PP strapping production line,

high productivity PP strapping machine
