Automatic Winding with 4 Independent Servo-Controlled Spindles

Automatic Winding with 4 Independent Servo-Controlled Spindles
Automatic Winding with 4 Independent Servo-Controlled Spindles

Large Image :  Automatic Winding with 4 Independent Servo-Controlled Spindles

Product Details:
Place of Origin: CHINA
Brand Name: CHUQI
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Packaging Details: WOODEN BOX
Delivery Time: 60DAYS
Payment Terms: T/T
Supply Ability: 100SETS
Contact Now

Automatic Winding with 4 Independent Servo-Controlled Spindles

Description
Station Count: 4 Independent Spindles Drive Method: Independent Servo Motors
Control Core: PLC Core Function: Automatic Fixed-Length Winding
Tension Control: Independently Adjustable Traversing System: Servo-Driven
Final Result: Neat Roll Formation
Highlight:

PP strapping band production line with automatic winding

,

servo-controlled spindles strapping production line

,

4-spindle automatic winding strapping machine

Automatic Winding with 4 Independent Servo-Controlled Spindles
Winding is the final process in the production line, directly impacting the appearance quality of finished rolls and their subsequent usability. This machine features a four-spindle independent automatic winding system where each spindle is driven by a dedicated 1.2KW servo reduction motor, enabling precise individual control of speed and tension. Combined with PLC intelligent control, it achieves automatic roll change at preset length, pre-alarm stop, and constant tension functions. The result is neat winding formation without loose or overlapping layers, significantly improving finished product yield and customer satisfaction.
Main Specifications
  • Structure: 4 independent winding stations (spindles)
  • Drive: Each spindle driven by an independent servo reduction motor (1.2KW)
  • Control: PLC centralized control with parameter setting via touch screen
  • Functions: Automatic stop at preset length, adjustable tension, neat winding
  • Advantages: High winding quality, high automation level, reduced labor requirements
Technical Parameters
Item Parameter
Number of Winding Spindles 4, independently controlled
Single Spindle Drive Power 1.2 KW Servo Reduction Motor
Compatible Core I.D. φ150 - φ300 mm (customizable)
Compatible Core Length 200 mm
Winding Line Speed 0 - 150 m/min (synchronized with main line)
Tension Control Method Servo torque control, manually settable (0.3-3N adjustable)
Customer Questions & Answers
What is the biggest advantage of "independent servo control" for winding?
The primary advantage is achieving true "per-spindle tension control". Even with minor variations in thickness or elasticity across the four straps, each servo motor performs fast, independent torque compensation based on its specific tension setting. This ensures each strap is wound at optimal tightness, completely eliminating uneven tension issues caused by shared power sources.
How is "automatic stop at preset length" achieved? What is the accuracy?
This function is accomplished through an electronic length counter at the front that measures strap length and sends real-time signals to the PLC. Operators preset the desired roll length (in meters) via the touch screen interface. When the target value is reached, the PLC controls the corresponding winding spindle to automatically decelerate and stop precisely while activating audible/visual alarms for roll change notification. Accuracy depends on the length counter system, achieving ±0.1%.
How is the neatness of winding (no overlapping edges) ensured?
Winding neatness is guaranteed by two key mechanisms: 1) Constant Tension Control: The servo system maintains stable winding tension, forming the foundation for uniform rolls; 2) Traversing System: An independent traversing device (guide wheel) driven by a 500W servo motor guides the strap back and forth. Its movement speed precisely matches the winding speed, ensuring the strap is wound evenly and flatly layer by layer on the core.

Tag:

synchronous PP strapping line,

PP strapping production line,

high productivity PP strapping machine
