Command Central Pp Strap Making Machine PLC-Computerized Control Hub For PP Lines

Large Image : Command Central Pp Strap Making Machine PLC-Computerized Control Hub For PP Lines

Product Details:

Place of Origin:	CHINA
Brand Name:	CHUQI

Payment & Shipping Terms:

Minimum Order Quantity:	1SET
Packaging Details:	WOODEN BOX
Delivery Time:	60DAYS
Payment Terms:	T/T
Supply Ability:	100SETS

Contact Now

Command Central Pp Strap Making Machine PLC-Computerized Control Hub For PP Lines

Description

Control Architecture:	Centralized PLC + HMI	Operator Interface:	Graphical Touch Screen
Core Function:	Multi-Group Process Recipe Management	Diagnostic Capability:	Real-Time Alarm & Fault Location
Data Management:	Production Logging & Historical Traceability	Communication Interface:	Ethernet, Supports Informatization
User Hierarchy:	Multi-Level Password Permission Management
Highlight:	PLC Pp Strap Making Machine , PP strapping band production line PLC , Pp Lines Strap Making Machine

Command Central: The PLC-Computerized Control Hub for PP Lines

Product Overview

Eliminate scattered controls with our highly integrated PLC-computerized control center—the intelligent brain of your production line. Through a clear, intuitive color touch screen interface, monitor every aspect of your operation: hopper drying temperature, extruder zone heating status, real-time line speed, tension and length count across four winding shafts, and fault alarm messages. Advanced recipe management enables one-touch recall of preset parameters when switching product specifications, significantly reducing setup time and minimizing human error. This system serves not only as an operator interface but also as a production data recorder and fault diagnosis expert, delivering unprecedented clarity, efficiency, and intelligence to your production management.

Main Specifications

Centralized Monitoring: 10-inch or larger color touch screen HMI with graphical dynamic display of full-line process flow, real-time digital display and trend logging of key parameters
Recipe Management: Stores dozens of product process recipes (temperature, speed, draw ratio, tension) with password protection to ensure process stability and repeatability
Linked & Independent Control: Supports automatic linked start/stop of the entire line, plus independent manual operation of each unit for simplified commissioning and maintenance
Intelligent Diagnosis & Alarm: Continuously monitors sensor and actuator status, immediately alerting to faults like overtemperature, overload, material break, or tension abnormality with fault point identification and corrective action suggestions
Data Communication: Standard Ethernet port supports remote monitoring (network configuration required) and data export, providing interface for factory informatization management (MES)

Technical Parameters

Parameter Category	Parameter Item	Specification / Description
Control Core	PLC Brand/Model	Xinje (XINJE) or equivalent
	Human-Machine Interface	≥10-inch Color Resistive/Capacitive Touch Screen
Function Configuration	Recipe Storage Capacity	≥50 sets
	Real-Time Data Logging	Key process parameters, output, runtime
	Alarm History Log	≥1000 entries with timestamp
Control Performance	Response Time	≤100ms
	Control Accuracy	Temperature ±1°C, Speed ±0.1%
Expandability	Communication Interface	Ethernet (RJ45), RS485
	I/O Point Reserve	≥15% for future expansion

Frequently Asked Questions

Q1: Is touch screen control reliable? Isn't it prone to damage or accidental touches?

We use industrial-grade touch screens with protection ratings, anti-interference capabilities, and service life that far exceed commercial products. The screen surface is protected by tempered glass against scratches. Critical operations (start, emergency stop, parameter changes) feature confirmation dialogs and hierarchical permissions (operator, engineer, administrator passwords), effectively preventing misoperation. These systems are proven in various industrial automation applications and fully meet the demands of 7x24 continuous production environments.

Q2: Can this system help us analyze production efficiency and identify bottlenecks?

Absolutely. The control system automatically logs start/end times, effective runtime, downtime duration and causes (via alarm records), and total output for each production run. By periodically exporting this data and performing analysis (calculating OEE - Overall Equipment Effectiveness), you can clearly see equipment time utilization and performance efficiency, accurately identifying whether planned stops, equipment failures, or speed losses are causing unmet capacity targets. This enables targeted management improvements and equipment maintenance.
